Lighting:
Sizes
High-output LED luminaire with advanced optics for uniform illumination
Premium LEDs provide up to 140LM/W efficiency
Available wattage and lumen output:
100W (14,000LM, 140LM/W), 150W (21,000LM, 140LM/W), 200W (28,000LM, 140LM/W), 300W (42,000LM, 140LM/W), 400W (56,000LM, 140LM/W)
Selectable CCT options:
3000K, 4000K, 5000K
CRI:
80 for optimized visibility
0-10V dimming standard for brightness control
Installation:
Multiple mounting options:
Cable suspension mount, Fixed bracket mount, 60° adjustable bracket mount
Compact and lightweight design for quick and easy installation
Temperature range:
-30°C to +50°C
Electrical:
Voltage Compatibility:
120V-277V (Standard), 347V-480V (Optional)
Optional Features:
Bluetooth mesh network for wireless control (up to 100 luminaires per network), Microwave or PIR motion sensor for occupancy-based control, Battery backup system (8W emergency driver for three hours of illumination)
Details & Accessories:
Durable aluminum housing with warm white powder-coated finish
Optional UGR<25 anti-glare lens upgrade for enhanced visual comfort
Polycarbonate lens for additional protection and simplified cleaning
6kV line-line, 10kV line-ground surge protection for electrical stability
Dust-proof and water-resistant with an IP66 rating
IK10 impact resistance for durability in high-impact environments
Certifications:
cULus Listed, DLC Premium Certified, IP66 Wet Location Rated, IK10 Impact Rated
Warranty & Lifespans:
5-year limited warranty, Rated lifespan: 60,000 hours
To add product to your project,
please sign up first
please sign up first
Resources
Technical Specs
GLI-LHBB_Linear_High_Bay.pdf
Installation Manual
GLI-LHBB-Linear-High-Bay-Installation-Manual.pdf
.IES Files
IES-GLI-LHBB-200W.zip
IES-GLI-LHBB-300W.zip
